Technical Specifications
Printing Technology
|
Fused Deposition Modeling |
|
Body
|
Build Volume (W*D*H) |
Single Nozzle Printing: 325*320*325 mm³ Dual Nozzle Printing: 300*320*325 mm³ Total Volume for Two Nozzles: 350*320*325 mm³ |
|
Chassis & Shell |
Aluminum, Steel, Plastic and Glass |
|
Laser Safety Windows |
Equipped on Laser Edition, normal H2D can upgrade through Laser Upgrade Kit |
|
Air Assist Pump |
Equipped on Laser Edition, normal H2D can upgrade through Laser Upgrade Kit |
Physical Dimensions
|
Physical Dimensions |
492*514*626 mm³ |
|
Net Weight |
31 kg |
Toolhead
|
Hotend |
All Metal |
|
Extruder Gear |
Hardened Steel |
|
Nozzle |
Hardened Steel |
|
Max Nozzle Temperature |
350 °C |
|
Included Nozzle Diameter |
0.4 mm |
|
Supported Nozzle Diameter |
0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm |
|
Filament Diameter |
1.75 mm |
|
Extruder Motor |
Bambu Lab High-precision Permanent Magnet Synchronous Motor |
Heatbed
|
Supported Build Plate Type |
Textured PEI Plate, Smooth PEI Plate |
|
Max Heatbed Temperature |
120 ℃ |
Speed
|
Max Speed of Toolhead |
1000 mm/s |
|
Max Acceleration of Toolhead |
20,000 mm/s² |
|
Max Flow for Hotend (Standard Flow Hotend) |
40 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature) |
|
Max Flow for Hotend (Optional High Flow Hotend) |
65 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature) |
Chamber Temperature Control
|
Active Chamber Heating |
Supported |
|
Max Temperature |
65 °C |
Air Purification
|
Pre-filter Grade |
G3 |
|
HEPA Filter Grade |
H12 |
|
Activated Carbon Filter Type |
Granulated Coconut Shell |
Cooling
|
Part Cooling Fan |
Closed Loop Control |
|
Auxiliary Part Cooling Fan |
Closed Loop Control |
|
Chamber Heat Circulation Fan |
Closed Loop Control |
|
Cooling Fan for Hotend |
Closed Loop Control |
|
Main Control Board Fan |
Closed Loop Control |
|
Chamber Exhaust Fan |
Closed Loop Control |
Supported Filament Type
|
PLA, PETG, TPU, PVA, BVOH, ABS, ASA, PC, PA, PET, Carbon/Glass Fiber Reinforced PLA, PETG, PA, PET, PC, ABS, ASA, PPA-CF/GF, PPS, PPS-CF/GF |
Supported |
Sensor
|
Live View Camera |
Built-in; 1920*1080 |
|
Nozzle Camera |
Built-in; 1920*1080 |
|
BirdsEye Camera |
Built-in; 3264*2448 （Equipped with Laser Edition) |
|
Toolhead Camera |
Built-in; 1920*1080 |
|
Door Sensor |
Supported |
|
Filament Run Out Sensor |
Supported |
|
Filament Tangle Sensor |
Supported |
|
Filament Odometry |
Supported with AMS |
|
Power Loss Recovery |
Supported |
Electrical Requirements
|
Voltage |
200-240 VAC, 50/60 Hz |
|
Max Power* |
2200 W@220 V / 1320 W@110 V |
Working Temperature
|
10 °C–30 °C |
|
Electronics
|
Touchscreen |
5-inch 720*1280 Touchscreen |
|
Storage |
Built-in 8 GB EMMC and USB Port |
|
Control Interface |
Touchscreen, mobile App, PC App |
|
Neural Processing Unit |
2 TOPS |
Software
|
Slicer & Software |
Bambu Studio, Bambu Suite, Bambu Handy Supports third-party slicers which export standard G-code, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported. |
|
Supported Operating System |
MacOS, Windows |
Wi-Fi
|
Operating Frequency |
2412-2472 MHz, 5150-5850 MHz (FCC/CE) 2400-2483.5 MHz, 5150-5850 MHz (SRRC) |
|
Wi-Fi Transmitter Power (EIRP) |
2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC) 5 GHz Band1/2: <23 dBm (FCC/CE/SRRC/MIC) 5 GHz Band3: <30 dBm (CE); <24 dBm (FCC) 5 GHz Band4: <23 dBm (FCC/SRRC); <14 dBm (CE) |
|
Wi-Fi Protocol |
IEEE 802.11 a/b/g/n |
