Technology
Quad-camera Infrared Structured Light
Single-frame Accuracy, up to
0.05 mm
Fused Point Distance, up to
0.05 mm
Single Capture Area at Nearest Distance
28 x 53 mm at 100 mm
Single Capture Area at Furthest Distance
975 x 775 mm at 1000 mm
Two Capture Modes:
Single-shot Mode , Continuous Capture Mode
Scanning Speed，up to
15 fps
Minimum Scan Volume
10 x 10 x 10 mm
Maxmium Scan Volume
4 × 4 × 4 m
Working Distance
100 - 1000 mm
Screen
6” 2k AMOLED Touch Screen
Auxiliary Lighting
Infrared Fill Lights, White Flash LEDs
3D Light Source
Class 1 Infrared Light
Storage
256 GB eMMC
Position Sensors
9-axis IMU
Memory (RAM)
16 GB
RGB Camera Resolution，up to
48 Megapixels
Scanner Weight
750 g
Dimensions（L x W x H）
200 x 50 x 110 mm
Battery Capacity
Internal lithium Battery 5,000 mAh, supporting up to 2-hour continuous scanning
CPU
8-core CPU，2.4 GHz
Tracking Methods
Feature, Marker, Global Marker
Protection Rating
IP45
Connector Type
USB Type-C
Wi-Fi Type
Wi-Fi 6
Compatible Operating Systems
Windows 10/11 (64-bit), macOS 11.0 or better
Operating System
Native Android System
Special Object Scanning
Use scanning spray for transparent, dark, or highly reflective objects
Scanning Environment
Indoors and Outdoors
Output File Formats
PLY, OBJ, STL, ASC, 3MF, GLTF, FBX
3D Printing Compatible
Yes
Built in Chip Computing
Depth Map Computing, 3D
Scanning, Point Cloud
Processing and Editing
Minimum PC Requirements*
macOS
CPU: M1 Pro or better; RAM ≥ 8GB
Windows
CPU: Intel i7 12th Gen or better; RAM ≥ 16GB
Recommended PC Requirements*
macOS
CPU: M3 or better; RAM ≥ 8GB
Windows
CPU: Intel i9 11th Gen or better; RAM ≥ 32GB
Note:
1. Precision is how close repeated measurements of the same object at a single angle are to each other. Accuracy is how close a measured value at a single angle is to the actual (true) value. They were both acquired in a controlled lab environment. Actual results might vary, subject to the operation environment.
2. Outdoor scans should avoid direct sunlight.
3. Class 1 Laser: Avoid direct eye exposure for extended periods! Refer to Standards for Class 1 Lasers for details.
4. Some products have flashing lights, which may not be suitable for people with photosensitive epilepsy.
5. The MIRACO series 3D scanners require no PC when scanning. But the PC requirements above should be followed if you connect the MIRACO to Revo Scan (PC) for more operations.
