Specifications
Model
PS-S02D/PS-S02E
Wireless Protocols
Wi-Fi IEEE 802.11 b/g/n 2.4 GHz, Bluetooth 4.2
Wi-Fi Operation Frequency
2412-2472 MHz
Wi-Fi Maximum Output Power
≤ 20 dBm
Bluetooth Operation Frequency
2402-2480 MHz
Bluetooth Maximum Output Power
≤ 13 dBm
Radar Operation Frequency
60-64 GHz
Radar Maximum Output Power
≤ 20 dBm (Only applicable to the EU region)
Dimensions
64 × 64 × 29.5 mm (2.52 × 2.52 × 1.16 in.)
Operating Temperature
-10°C ~ 40°C (14°F ~ 104°F)
Operating Humidity
0 ~ 95% RH, no condensation
Protection Rating
IPX5
Ports
USB-C
Input Power
5V==1A
What's in the Box
PS-S02D: Presence Sensor FP2 × 1, User Manual × 1, USB-C to USB-A Cable × 1, Metal Plate × 2, Sticker ×2, Screw Kit × 1 PS-S02E: Presence Sensor FP2 × 1, User Manual × 1, USB-C to USB-A Cable × 1, Metal Plate × 1, Sticker ×1, Screw Kit
